Precision Parallel Set 14 Pairs Hardened
Part Number: JF-00029
Price on request
Available to order
Fourteen pairs of hardened and ground precision parallels, 150 mm long, in a fitted case.
Specifications
| Number of pairs | 14 |
| Length | 150 mm |
| Thickness | 10 mm |
| Height range | 8 - 40 mm |
| Accuracy | 0.01 mm |
| Hardness | 58 - 62 HRC |
| Material | Hardened tool steel |
Description
Fourteen matched pairs of hardened and ground parallels, 150 mm long, in graduated heights. Parallels set the workpiece at a known height above the vise bed so the cutter clears the jaws, and their accuracy transfers straight into the part: if the pair is not matched, the part comes out tapered. Ground to 0.01 mm on thickness and parallelism, matched in pairs and marked. Hardened to 58-62 HRC so a dropped parallel dents rather than deforms.
