Toe Clamp Set 4 Piece M12
Part Number: JF-00032
Price on request
Available to order
Four low-profile toe clamps, M12, gripping the workpiece edge from above and below.
Specifications
| Thread size | M12 |
| Number of pieces | 4 |
| Clamping height | 8 - 25 mm |
| Base length | 50 mm |
| Base width | 32 mm |
| Material | Hardened steel |
| Type | Low-profile toe clamp |
Description
A set of four low-profile toe clamps. A toe clamp grips a shallow chamfer or a plain edge and pulls the part down onto the fixture, holding it with almost nothing standing above the workpiece surface. That clearance is the point: a strap clamp stands proud and the cutter has to work around it, whereas a toe clamp leaves the whole top face open in one setup. Best on parts with a machined edge to bite on.
